12/24V system automatic detectable
PWM charging available
With small self consumption, 2mA at 12V system
3-stage charging algorithm: impulse, bulk and float
Wrong battery pole connection protection
Light sensor adjustable
Adjust the timer and light sensor
Lightning protection
Item Display
Specification
Maximum Charging Current: 45A
Maximum Loading Current: 45A
Rated Voltage: 12V/24V
Temperature Compensation: -4.7mv/cell· °C
Charging Circuit Voltage: <200mv
Environment Temperature: -15 °C~+60 °C
Charge Off Voltage: 13.7v/27.4v
Load Off Voltage: 10.5V/21V
Load On Voltage: 12.6V/25.2V
MAX Solar Panel: 540W/1080W
Waterproof Class: IP22
100% Customer Satisfaction Guarantee:
Here at ecoworthy2003, we strive to serve our customers and resolve any issues.
If your shopping experience with us is anything less than five stars, please contact us immediately. We appreciate the opportunity to correct any issues you have before you leave feedback.
We appreciate your business and consideration.
We are manufacturers and wholesalers of solar panels and renewable energy products. Our solar business has been established since 2002. Our engineers are experienced in solar and related accessories, if you buy from us you deal with not just a seller, the whole technical team is behind you and your business. OEM and ODM services are both available. We would like to be your best supplier in China.
